WFJ Micro Grinder

The equipment consists of main machine, assistant machine and control cabinet.The process of produce is continuous.The machine is extensively used in pharmaceutical, chemical, food industries for pulverizing dry brittle materials .

: 24-Hour Hour Hotline:
0086-18962409901

: Inquire

: Micro Grinder

: Micro Grinder

Description

APPLICATION

The grinder consists of main machine, assistant machine, and control cabinet. The process of produce is continuous. The machine is widely used for the fragile materials in pharmaceutical, chemical, and food industries.

Technical Parameter

Spec	Unit	WFJ-15	WFJ-18	WFJ-32
Production capacity	kg/h	10-200	20-450	60-800
Inlet material diamenter	mm	＜10	＜10	＜15
Oulet material diamenter	mesh	80-320	80-450	80-450
Power	kw	13.5	17.5	46
Main rotaing speed	r/min	3800-6000	3800-6000	3800-4000
Overall dimension(L×W×H)	mm	4200×1200×2700	4700×1200×2900	9000×1500×3800
Weight	kg	850	980	1500
